Bollo BAR-II Ver2.0 Bluetooth HiFi Audio Receiver





- Allows you to get rid of the shackles of the cables, to enjoy the convenience of airplay and high-fidelity sound.
- Supports any mobile phone, pad, laptop, computer with bluetooth function.





Product Features:

- Wireless, Airplay Concept
- Small body, High Fidelity Sound
- Easy to use, no dock needed
- Free your mobile device when you enjoy music
- Specifically optimized sound quality for Apple's iPhone and iPad product
- Bluetooth 4.0, Apt-X available



How to use:

    - The BAR-II own a set of RCA audio output terminals. You can directly connect to the audio input terminals of amplifier or active speakers.
    - The BAR-II come with a RCA to 3.5mm headphone jack adapter cable, you can use it to connect headphones or computer speakers
    - After power on the BAR-II, to active the bluetooth function of your mobile phone or pad , search for bluetooth device, you'll find a device named "bollo"
    - Connecting the "bollo", the match code is four zero ( 0000). If your connection failed , Please re-power on it and try to connect again.



    Interface :
    · Input: 1 x Bluetooth Ver4.0 with apt-X supported
    · Output: 1 set of RCA Stereo
    · Power Supply: DC 5V/1A


    Bluetooth Module Parameter :
    · CSR8645 Bluetooth® 4.0 Core
    · Frequency Range: 2.4~2.48GHz
    · Modulation: GFSK, 1Mbps, 0.5BT Gaussian
    · Maximum Data Transfer Rate: > 3Mbps
    · Hopping: 1600hops/sec, 1MHz channel space
    · RF Output Impedance: 50ohms
    · Crystal Frequency: 26MHz
    · Bluetooth Protocol Supported: OPP, OBEX, SPP, A2DP, AVRCP, FTP, HS/HF, DUN Profiles
    · Operation Distance And Range: in 10 meters Class Ⅱ
    · Receiver Sensitivity: -80dBm@0.1% BER
    · Transmit Power: < 4dBm
    · Connection: Point to Multi-Points
    · Audio Performance: High acoustic fidelity sound
    · Audio Encoding Bit: 16bits
    · Signal to Noise Ratio: >95dB
    · Audio encryption Algorithm: 128bits
    · Audio Output: Stereo analogue Audio
    · Stereo Output Level: 2.0V
    · Frequency Response: 20~20KHz±0.5dB
    · Noise Level: < -93dB (A)
    · Dynamic Range: >92dB (A)
    · THD : < 0.02%
    · THD+Noise: < -90dB (A)
    · Stereo Crosstalk : < -90dB
    · IMD @ 10KHz: < 0.1%
    · Temperature Range: -40°C to +80°C
    · Humidity Range: 10%~90% Non-Condensing
    · Certificate: BQB, CE, FCC
